Thermo Haake DK15 - Accessories; Technical Specifications

Accessories Order No.
Clamp mounting for fixing the
EK20 or EK30 to bath walls
up to a thickness of 25 mm 333–0452
Technical specs. acc. to DIN 58966 DK15 EK20 EK30
Working temperature range °C –15..150 –20..150 –30..150
Cooling capacity at +20°C W 300 300 500
at –10°C W 150 150 250
at –40°CW – – –
at –70°CW – – –
Hose length cm – 150 150
Cooling coil dimensions (∅xL) mm – 81 x 145 81 x 195
Connecting nozzles (∅)mm 12 and 8 – –
Evaporator material stainless steel stainless steel stainless steel
Overall dimensions (WxLxH) mm 225x465x380 225x465x380 225x465x380
Weight kg 22 22 23
Ambient temperature range °C 10..40 10..40 10..40
Total power consumption VA 400 400 600
Order no. for 230 V/50–60 Hz 106–1151 322–1201 323–1301
for 115 V/60 Hz 106–1152 322–1202 323–1302
Cooling down times with the EK30
Cooling down times with the EK20
Cooling down time [min]
Cooling down time [min]
Working temperature [deg C] Working temperature [deg C]
Accessories / Technical Specifications
