TK 61652-18-OP-EN

TK Batteries HMI Menu

Figure 10. Battery Life Display Screen showing Battery 1 @ 70.1%

This Icon represents a Percentage symbol %

HMI in Shorepower operation

When the unit is connected to shore power and is off (HMI – OFF), in the HMI

appears information regarding the status of the battery, showing the

messages:

• UntOFF (unit Off)

• bL1, bL2 (Battery life: a parameter from 0 to 100% showing the battery

charge)

OOppeerraattiinngg IInnssttrruuccttiioonnss
