Thermo King Spectrum - Condenser; Evaporator

TK 61651-18-OP-EN
23
Figure 5. Compressors
1. Swash Plate
2. Reciprocating
Condenser
The condenser is located on the roof of the vehicle or on the front of the
cargo box. The cover can easily be removed to access the fuses or service
the unit.
Figure 6. Condenser
Evaporator
The evaporator is mounted on the ceiling inside the cargo box. The cover
can easily be removed for service.
Figure 7. Evaporator
