Specifications
46
Fuses
Fuse Size Function
F2 15A Power to On/Off Switch
F3 40A Fuel Sol Pull-In/Starter Circuit
F4 None
2A
No Fuse - All Bosch and Thermo King Alternators
2A Fuse - All Prestolite Alternators
F5 40A Preheat Circuit
F6 15A High Speed Circuits
F7 2A 8XP Circuit - Controller On Feedback to HMI
F8 5A 2A Power to CAN Connector J12
F9 5A 2A Power to CAN Connector J14
F10 10A 8X Power (Install fuse in upper position)
F11 10A Zone 1 LLS
F12 5A CAN Connector J13
F13 2A 8FC Circuit (Remote Lights)
