38
Status
Path: Status
This menu displays a summary of the important parameters which have been set.
SYSTEM
This shows the type of applications (gravity, etc.), the filter type, the current sample rate (SR), and if a
photo eye is present.
PHASE
This displays the current phase point, the phase state (auto, fixed), the mode, and the state of residual compensation.
GAIN
This shows the state of the gain, the R and X thresholds, and the current sensitivity.
REJECT
This displays the current delay/duration of the reject system.
PASSWORD
This displays the current state and level of password protection and the QA Test state.
