Thermo Scientific DSP2 - Status Screen

45
DSP 2 Calibration Record
Company : Date :
Location : Serial Number :
Aperture Size : Wide by High
Line :
Product name: Number :
Status Screen
FAULT
LEARN
PRODUCT
FUNCTION
DETECT
TEST
ALARM
RESET
EXIT
System: Conveyor dnr1 sr=62 no-eye
Phase: 90.16 Fixed Dry Res=off
Gain: high R=100 X=100 Sens=100
Reject: del=0.50 secs dur=0.75 secs
Password: Off Level 3 QATest=normal
Photo=off Mode=normal
Service Data
System: dnr: sr: eye:
Phase: Fixed / Auto / Hold Mode: Wet / Dry / Hold Res: Off / Auto / Fixed / Hold
Gain: R= X= Sens=
Reject: del= dur=
Photo= Mode=
Password: QaTest=
Service Data Screen
FAULT
LEARN
PRODUCT
FUNCTION
DETECT
TEST
ALARM
RESET
EXIT
Frequency: 300Khz
Levels: bal=18 refA=200 refB=112
Version: 2960412
Scope Previous Page
Frequency :
Levels : bal= refA= refB=
Version :
Misc. Data
Phase Mode : (Path: Setup/Configure Learn/Mode)
Reject Check : (Path: Setup/Reject/Special/Rej Confirm Sensors)
Eye Distance : (Path: Setup/Application)
Belt Speed : (Path: Setup/Application)
Detect Mode : (Path: Setup/Configure Learn/Sensitivity)
