Manual HS-4-C V.2.1 ENG Original Version QC/TDPT/mn March 2020 15
thermopatch.com
Controller Board
ITEM
#
DESCRIPTION QTY Part Num-
ber
5 Electrical Chassis 1 46326
6 #4-40unc x ¼” Socket Hex Cap Screw 4 21063-02-C
7 #4 Spring Lockwasher 4 21031-03-C
8 Controller Board 1 46411
Figure 6 – Controller Board
