Manual HS-4-C V.2.1 ENG Original Version QC/TDPT/mn March 2020 18
thermopatch.com
Extension Spring Assembly
ITEM
#
DESCRIPTION QTY Part Num-
ber
19 Extension Spring 1 24080-35
20 Bumper 2 24091-44
21 Base Frame Assembly 1 47263
Figure 9 – Extension Spring Assembly
