Thinget XC3-24RT-E - Page 202

Applied Instructions
D10 (Hour)
D11 (Minute)
D12 (Second)
D20 (Hour)
D21 (Minute)
D22 (Second)
D30 (Hour)
D31 (Minute)
D32 (Second)
+
S1 S2
D
10 hour 20 min. 30 sec.
3 hour 20 min. 10 sec.
13 hour 40 min. 40 sec.
18 (Hour)
10 (Minute)
30 (Second)
10 (Hour)
20 (Minute)
5 (Second)
4 (Hour)
30 (Minute)
35 (Second)
+
S1 S2
D
18 hour 10 min. 30 sec.
3 hour 20 min. 10 sec.
4 hour 30 min. 35 sec.
Function & Action
z Each of S1, S2 and D specify the head address of 3 data devices to be used a time value.
The time value in S1 is added to the value in S2, the result is stored to D as a new time
value.
z If the addition of the two times re a value greater than 24 hours, the value of the
result is the time remaining abov urs. When this happens the M8022 is
sults in
e 24 ho carry flag
z When the result is 0（0 Hour 0 Minute 0 Second），Set zero fla
g
ON.
The valid range of “Hour” is「0~23」.
The valid range of “Minute” is「0~59」.
The valid range of “Second” is「0~59」.
(D10, D11, D12)＋（D20, D21, D22）→（D30, D31, D32）
TADD
D10
D20
D30
X0
S1·
S2·
D·
[TADD]
16 bits instruction：DIV 32 bits instruction：DDIV
Suitable Models：
XC3、XC5
¾
Word
Device
Bit
Device
D
FD
DM
DX
DY
DS
TD
CD
K/H
S1·
S2·
D·
X
Y
M
S
T
C
Dn.m
202
