Thinget XC3-24RT-E - Device’s ID List

Function of each device
3-2. Device’s ID List
For the allocate of device’s ID, please see the following list：
Besides, when connect input / output expansions and special expansions on the basic units, for
the input / output relay’s No., please refer to the user manual.
Bound points
Mnemonic Name
14 points 24\32 points 48 \60 points
14
points
24\32
points
48 \60
points
X Input relay X000~X007
X000~X015
X000~X021
X000~X033
X000~X043
8 points
14\18
points
28\36
points
Y Output relay Y000~Y005
Y000~Y011
Y000~Y015
Y000~Y023
Y000~Y027
6 points
10\14
points
20\24
points
M0~M2999【M3000~M7999】 8000
M Interior relay
M8000~M8511 for special using 512
S Flow
S0~S511
【S512~S1023】
1024
T0~T99：100ms not accumulation
T100~T199：100ms accumulation
T200~T299：10ms not accumulation
T300~T399：10ms accumulation
T400~T499：1ms not accumulation
T500~T599：1ms accumulation
T Timer
T600~T618：1ms with interruption precise time
620
C0~C299：16 bits forth counter
C300~C598：32 bits forth/back counter
C Counter
C600~C634：high-speed counter
635
D0~D3999
【D4000~D7999】
8000
D Data Register
For special usage D8000~D8511 512
FD0~FD1535 1536
FD
FlashROM
Register
For special usage FD8000~FD8511 512
