Installing the product
13
2
After determining the installation location, wipe the installation location on the windshield with a dry
cloth.
3
2
1
➊➊
➋➋
Attach the shield film to the installation location.
4
2
1
➊➊
➋➋
Remove the protective film from the adhesive mount,
and then press the mount to the shield film.
5
2
1
➊➊ ➋➋
Remove the product from the mount and push the
mount against the windshield to ensure that the
mount is firmly fixed.
6
Align the product to the mount, and then slide it into
the locking position until you hear a click.
• The product may fall and be damaged during
vehicle operation if it is not firmly fixed to the
mount.
• If you need to remove the mount from the
windshield to alter the installation location, be
careful not to damage the windshield’s film coat.
