Thinkware Q1000 - Connecting the Power Cable; Installing the Rear Camera (Optional)

Installing the product
14
7
Set the vertical angle of the camera appropriately.
If the product and mount are not fully connected,
the red part of the slide lock will show.
To confirm the camera angle, record a video after installation and check the video using the mobile
viewer or the PC viewer. If necessary, adjust the camera angle again. For more information about the
mobile viewer or the PC viewer, refer to "4. Using the mobile viewer" on page 24 or "6. Using the PC
viewer" on page 26.
2.1.3󳒀 Connecting the power cable
When the engine and electrical accessories are turned off, connect the car charger.
The hardwiring cable (optional) must be professionally installed to the vehicle by a trained mechanic.
2
DC-IN
RADAR
1
➊➊
➋➋
Connect the car charger to the product’s DC-IN power
port and insert the cigar jack into the vehicle’s power
socket.
The location and specifications of the power socket
may differ by vehicle make and model.
•󳒀 Use the authentic THINKWARE car charger. Use of third party power cables may damage the product and
result in electrical fire or electrocution due to the voltage difference.
•󳒀 Do not cut or modify the power cable yourself. Doing so may damage the product or the vehicle.
•󳒀 For safe driving, arrange the cables to prevent the driver's vision from being obstructed or interfering with
driving. For more information about arranging cables, visit www.thinkware.com.
