5.4.1 Sound displays structure
1 Shows the currently selected pad.
2 Shows the sample level of layer mode.
In layer mode, the pads can be assigned in such a way that, depending on the
intensity of the strike, dierent sounds in dierent volumes with dierent
eects are generated on the same pad.
Hit the pad to select sample ‘A’ or sample ‘B’ for editing. Please note that it is
not possible to select sample ‘B’ , when ‘Type’ is set to ‘OFF’ , and set the ‘Layer
point’ respectively.
3 Shows the name of the currently selected sound to which the currently edited
pad is linked.
Use the rotary control or press [–/+] to change the sound. Conrm the selec‐
tion with [OK].
4 Shows the volume of the selected sound.
Use the rotary control or press [–/+] to change the overall volume of the sound
between ‘0’ and ‘127’ . Conrm the selection with [OK].
5 Shows the setting of the layer mode.
If the pad is set to have both sample ‘A’ and sample ‘B’ , any time you hit the
pad that is louder than the set threshold ( ‘0’ … ‘127’ ), sample ‘B’ will be
played. If, for example, the threshold is set to ‘50’ , sample ‘A’ will be played
when you hit the pad quieter than ‘50’ , sample ‘B’ when you hit the pad
louder than ‘50’ .
Use the rotary control or press [–/+] to change the threshold for switching
from sample ‘A’ to sample ‘B’ from ‘0’ to ‘127’ . Conrm the selection with
[OK].
6 Shows the functioning of the layer mode.
‘OFF’ : only sample A is played.
‘MIX’ : when the set threshold value for the layer mode is reached, sample ‘B’ is
overlaid with sample ‘A’ .
‘SWITCH’ : when the set threshold value for the layer mode is reached, sample
‘B’ will replace sample ‘A’ .
‘FADE’ : when the set threshold value for the layer mode is reached, sample ‘B’
is played in the same way as sample ‘A’ .
Use the rotary control or press [–/+] to change the functioning of the layer
mode. Conrm the selection with [OK].
Operating
NonaPad
13
