WIRELESS COLOUR VIDEO INTERCOM WITH OP-
TIONAL VIDEO SURVEILLANCE
EN
10
C - INSTALLATION
Control a gate motor
• Your exterior panel can either be powered with the 12V mains adapter provided or with batteries. You
can remotely open a motorised gate.
To connect your gate motor, follow the diagrams below according to your model of exterior panel.
Model A
12V/1A mains
adapter
(optional)
Or
Dry contact for opening a
motorised gate (example:
entry with key-operated
switch)
Dry contact for opening a
motorised gate (example:
entry with key-operated
switch)
Model B
Or
Dry contact for opening a
motorised gate (example:
entry with key-operated
switch)
Dry contact for opening a
motorised gate (example:
entry with key-operated
switch)
LOCK
12V/1A mains
adapter
(optional)
