WIRELESS COLOUR VIDEO INTERCOM WITH OP-
TIONAL VIDEO SURVEILLANCE
11
EN
C - INSTALLATION
2 - INSTALLATION OF THE EXTERIOR PANEL
• Attach the shield for the exterior panel to your
chosen outdoor location using the appropriate
screws and wall plugs (the screws and plugs
supplied are suitable for walls made of solid
material).
• After installing the batteries and/or connecting
the wires for the exterior panel, place it in its
shield. Then, screw the exterior panel to the
shield with the screws provided.
120mm
50mm
ø7mm
