WIRELESS COLOUR VIDEO INTERCOM WITH OP-
TIONAL VIDEO SURVEILLANCE
EN
8
C - INSTALLATION
1 - POWER FOR THE EXTERIOR PANEL
With batteries
• Open the battery compartment on the back
of the exterior panel and insert six 1.5V LR6
batteries (not included).
With mains adapter
• It is also possible to power the exterior panel
with the 12V DC 1A mains adapter (provided)
and the red and black power cord. In this
case, no batteries should be inserted.
LOCK
