WIRELESS COLOUR VIDEO INTERCOM WITH OP-
TIONAL VIDEO SURVEILLANCE
7
EN
B - PRODUCT DESCRIPTION
3 - EXTERIOR PANEL 4 - MAINS ADAPTERS
• A 230V AC 50 Hz/5V DC 1A mains adapter
for powering the monitor is included in the kit.
• A 230V AC 50 Hz/12V DC 1A mains adapter
for powering the exterior panel is included in
the kit if you want to power an electric strike
plate and have access to surveillance mode
(the video can be viewed without a call from
outside).
Do not use other power supplies as they could cause
irreparable damage to the device and invalidate the
warranty.
5 - INSTALLATION CD
The CD provided allows you to view on a computer
video footage recorded on a memory card (not
included) in the monitor.
1 Infrared light for night vision
2 Camera lens
3 Loudspeaker
4 Microphone
5 Call button + name plate
6 Pairing button
7 Battery compartment
8 Connection terminals
Front view
5
2
1
3
4
6 7 8
Rear view
