TS 870 Transfer Switch
PM062 REV 11 16/04/19 38 Thomson Power Systems
3. Pull the manual handle towards yourself to dis-engage the manual handle rod
from the motor drive mechanism.
4. To manually operate mechanism, push Manual Operation Handle knob handle up
or down to the desired position as labeled on the ATS Toggle arms.
5. Once ATS is manually operated to desired position, re-close ATS enclosure door,
then re-energize supply sources to re-energize the load.
