12. CABLE TERMINAL INFORMATION
BASIC MODEL
TERMINAL RATING
CONNECTION TIGHTNESS
(In-lbs.)
QTY
PER
PHASE RANGE
TERMINAL
MOUNTING
SCREW
CABLE
CLAMP
TS 87xA-0100 1 #14-1/0 120 50
TS 87xA-0150 1 #2–4/0 120 120
TS 87xA-0200 1 #6–350MCM 150 275
TS 87xA-0250 1 #6–350MCM 150 275
TS 87xA-0400
1
2
2/0–
500MCM
72 275
TS 87xA-0600
1
2
2/0–
500MCM
72 275
TS 87xA-0800
1
3
2/0–
500MCM
110 375
TS 87xA-1200
1
4
4/0–
500MCM
375 375
1. Optional terminal ratings are available in some models – Consult Thomson Power Systems.
2. For other model types not shown, contact Thomson Power Systems for further information.
