13. REQUIREMENTS FOR UPSTREAM CIRCUIT PROTECTIVE DEVICES
13.1. WITHSTAND CURRENT RATINGS (ALL MODELS WITHOUT INTEGRAL
OVERCURRENT PROTECTION OPTION)
BASIC MODEL
MAX.
VOLTA
GE
RATED
CURREN
T (A)
WITHSTAND CURRENT
RATING AMPS (RMS)
1
@240V
@480V
@600V
TS87xA-0100 600 100 65,000 25,000 18,000
TS87xA-0150 600 150 65,000 25,000 18,000
TS87xA-0200 240 200 65,000 N/A N/A
TS87xA-0250 600 250 65,000 35,000 25,000
TS87xA-0400 600 400 65,000 50,000 35,000
TS87xA-0600 600 600 65,000 50,000 35,000
TS87xA-0800 600 800 65,000 50,000 35,000
TS87A-
1000/1200
600
1000/120
0
65,000 50,000 42,000
1. Standard ratings only are shown. Consult Thomson Power Systems for versions
with higher withstand current ratings.
2. For other model types not shown, contact Thomson Power Systems for further
information.
