5 Appendix
15
5 Appendix
5.1 Technical Data PM160
Specification
PM160
Sensor Specifications
Wavelength Range
400 to 1100 nm
Optical Power Measurement Range
10 nW to 2 mW (1 µW - 200 mW)
1)
Optical Power Resolution
100 pW (10 nW)
1)
Measurement Uncertainty
+/- 3% @ 451 to 1000 nm
+/- 5% @ 400 to 450 nm and 1001 nm – 1100 nm
Power Linearity with Optical Power
± 1%
Active Area Uniformity
± 1%
Slideable Optical Filter
Reflective ND [OD1.5] with diffuser
Average Power Density (Max)
1 W/cm² (20 W/cm²)
1)
Sensor Aperture
Ø 9.5 mm
Aperture Thread
SM05 with included adapter
Distance to Sensor
1.7 mm (4.2 mm)
1,4)
Sensor Thickness
3.5 mm (6.0 mm)
1,4)
Power Meter Specifications
Analog Measurement Ranges
500 nA, 50 µA, 5 mA
2)
AD Converter
24 bit
Analog Amplifier Bandwidth
10 Hz
Built-in Display
Monochrome white OLED 24.0 mm (0.95") across diagonal, 96 x 64 px
Local Operation
4 push buttons
Remote Interface
USB 2.0, Bluetooth 2.1 (Class II, 10 dBm)
General Data
Overall Dimensions
172.7 mm x 36.4 mm x 13.0 mm
Weight
60 g
Operating Temperature
0° C - 50° C (32 °F - 122 °F)
Power Supply
External: 5VDC via USB
Internal: LiPo+ 380 mAh
3)
Battery-Powered Operation
Up to 20 hours
Mounting Options
8-32 (imperial) and M4 (metric) tap combined, 3 positions
1
) Values in ( ) are with filter slided in.
2
) The appropriate range is chosen internally by the power meter to achieve the best accuracy.
3
) The battery is recharged through the USB connection.
4
) See chapter Dimensions for precise distances.
All technical data are valid at 23 ± 5°C and 45 ± 15% rel. humidity (non condensing).
