5.2 Technical Data PM160T, PM160T-HP
Specifications
PM160T
PM160T-HP
Sensor Specifications
Wavelength Range
190 nm to 10600 nm
190 nm to 20000 nm
Optical Power Measurement
Range
100 µW to 2 W
10 mW to 70 W
1)
Optical Power Resolution
10 µW
1 mW
Measurement Uncertainty
+/- 3% @ 1064 nm
+/- 5% (Entire Range)
+/- 3% @ 1064 nm
+/- 5% (250 nm to 17000 nm)
Power Linearity with Optical
Power
± 1%
Active Area Uniformity
± 1%
Average Power Density (Max)
500 W / cm
2
2 kW / cm
2
Sensor Aperture
Ø 10.0 mm (0.39 ")
Ø 25.2 mm (0.99 ")
Sensor Coating
Black Broadband
High Power Broadband
Adapter Plate Aperture Thread
SM1 with included adapter
Internal SM1 (1.035"-40);
Adapter to external thread included;
4 x 4-40 Tapped Holes on the Back
of the Sensor (compatible with 30
mm cage system)
Distance to Sensor
4)
2.6 mm
4.5 mm
Sensor Thickness
4)
5.5 mm
13.0 mm
Power Meter Specifications
Analog Measurement Ranges
1.6 mV, 25 mV, 400 mV
2)
2.56 mV, 16 mV, 100 mV
2)
AD Converter
24 bit
Analog Amplifier Bandwidth
10 Hz
Built-in Display
Monochrome white OLED 24.0 mm (0.95") across diagonal, 96 x 64 px,
10 Hz refresh rate
Local Operation
4 push buttons
Remote Interface
USB 2.0, Bluetooth 2.1 (Class II, 10 dBm)
General Data
Overall Dimensions
172.7 mm x 36.4 mm x 13.0 mm
206.0 mm x 56.0 mm x 13.0 mm
Weight
60 g
130 g
Operating Temperature
0°C - 50°C
Power Supply
External: 5VDC via USB
Internal: LiPo+ 380 mAh
3)
Battery-Powered Operation
Up to 20 hours
Mounting Options
8-32 (imperial) and M4 (metric) tap
combined, 3 positions
8-32 (imperial) and M4 (metric) tap
combined, 3 positions
4 x 4-40 Tapped Holes on Back of
Sensor for Ø6 mm Cage Rods
1
) Maximum exposure time: 70 W - 10 s; 30 W - 60 s; 10 W - 1 hour. Please see also back of the device.
2
) The appropriate range is chosen internally by the power meter to achieve the best accuracy.
3
) The battery is recharged through the USB connection.
4
) See chapter Dimensions for precise distances.
All technical data are valid at 23 ± 5°C and 45 ± 15% rel. humidity (non condensing).
