Compact Stabilized Light Sources Chapter 5: Specifications
Page 16 CTN002682-D02
Chapter 5 Specifications
Specifications SLS201L(/M) SLS202L(/M)
Wavelength Range
360 2600 nm
4505500 nm
Peak Wavelength
1
1000 nm
1500 nm
Color Temperature
2796 K
1900 K
Color Temperature Stability
±15 K
Bulb Power
9 W
7.2 W
Fiber Coupled Output Power (Typical)
10 mW
2
1.5 mW
3
Free Space Output Power
(Typical)
4
500 mW
700 mW
Collimated Output Power
(Typical)
5
60 mW
15 mW
Beam Divergence without Fiber Coupler
6
8.2°
13.8°
Collimated Beam Divergence
5,6
1.4°
Collimated Beam Diameter
5,7
24 mm
10 mm
Output Power Drift per Hour (Typical)
0.01%
Optical Power Drift per °C (Typical)
0.1%
Output Power Stability
8
< 0.05%
Power Supply
100 – 240 VAC
Operating Temperature
0 to 45 °C
Storage Temperature
-15 to 70 °C
Dimension
(L x W x H)
216.4 mm × 55.0 mm x 57.5 mm
(8.52" × 2.17" × 2.26")
1
Theoretic Value based on Black Body Radiation.
2
Measured with Included fiber patch cable at beginning of bulb lifetime.
3
Measured with Thorlabs MZ41L1 ZrF
4
MIR patch cable at the beginning of bulb lifetime.
4
Measured at the output port of the light source with fiber coupler removed.
5
Measured with optional collimator accessory.
6
Half Angle, Design Value @ 587 nm
7
Measured 10 cm away from the collimating lens.
8
Standard deviation of optical power value in percentage, measured at room temperature
over a 1 hour period with 1 Hz sampling rate after 45 minutes warm-up.
