GLASSWARE SANITIZING APPLIANCE
User and maintenance manual
RE V. 4
17
ENGLISH
7.2. COMPONENTS
Check that the package contains all the following items supplied as standard:
1) Glass sanitizer appliance;
2) power charger
3) Power charger cable
4) Instruction Manual
5) Statement of compliance with EC Directives
6) Kit for mounting the appliance to the worktop.
7.3. INSTALLATION
1) Make a 19.5 x19.5 cm square hole in the chosen work surface, bearing in mind that a gap of 2
cm minimum must be left around the body of the appliance;
2) Mount the appliance to the surface and lock into place with the mounting kit supplied – as
indicated in the gure below;
The technical features of the Vortex SBI are described in the following table:
Model VORTEX SBI
Power adapter for charger 100 – 240 Vac, 50/60 Hz
Battery charger plug CEE 7/16 in compliance with Italian standard CEI 23-5
Maximum power consumption when charging 56 W
Jet spray pressure 1 bar
Spray duration relative to time pressure applied
Level of IP2X protection exclusively when operated internally
Physical characteristics
Operational temperature from +10 to +40 ° C
Maximum operating altitude 2000 meters
Noise generated during spraying 89 dBA
Vibration generated during spraying not sucient to pose any danger
Size and weight of packaging 30 x 30 x 28 cm; weight 7 Kg
Maximum number of stackable units when
packaged
3
Size and weight of sanitizing appliance 20 x 20 x 25 cm
Size and weight of power charger 11.5 x 5 x3 cm; 220 gr,
Power cable length - 140 cm
Size and weight of 4 litre cylinder dia 14; length 59 cm; weight 11.3 Kg
Size and weight of 10 litre cylinder dia19 ; length 76 cm; weight 26 kg
CO2 cylinder connection UNI4406 ISO 5145 Gr2 W 21.7 x 1/14 “Ø 27 x 2
Appliance dimensions once tted into
work top
22 x 22 cm
Dimensions of square hole required for
installation
19.5 x 19.5 cm
Thickness of worktop on which to be
mounted
1 to 4 cm
