4
3
4
2
2
A B
AB
6mm(L)
Ball Stud
球頭座
1
2
4
3x12mm
BT Philip Machine Screw
圓頭十字螺絲
2
1
2
14x10.5.x0.1mm
Diff Shim
差速箱墊片
3
4x4mm
Set Screw
內六角螺絲
4
A B
A B
B
B
Camber Adjustment
外傾角調整
For Ready Set Camber Linkage
For Optional Turnbuckle Linkage
Not Recommended Set Up
Front Differential Unit 前差速箱
STEP5
Front Suspension 前擺臂懸吊組
STEP6
2
3
2
1
1
Pay close attention here
注意組裝步驟
Apply threadlocker
使用螺絲防鬆膠
Hint
組裝提示
Always adjust the front and rear bushings at the same time. Your car may not run
stable if front and rear bushings are unbalanced.
調整時請同時更換前後擺臂軸套。不平衡的設定將增加車輛行駛的不穩定性。
Inner hinge Pin
擺臂軸
1
2
2
6mm(S)
Ball Stud
球頭座
2
3x10mm
F/H Philip Machine Screw
平頭十字螺絲
3
2
Track
arm
mount
bushings
擺臂軸套
Low Speed Track High Speed Track
高速路面多彎
路況
防潛角度調整
Anti-Squat
Adjustment
Front
Front Front
Front
Rear Rear
Rear Rear
1
1
7
適用原廠固定式上臂拉桿
適用改裝可調式上臂拉桿
非原廠建議調整孔位
Factory Set-up
原廠設定
Apply grease
使用潤滑油膏(黃油)
Factory Set-up
原廠設定
To Next Page
