THUNDER TIGER Sparrowhawk XXT Maintenance Manual & Parts Catalogue

Assemble left and right side the same way
左右側組件相同
Hint
組裝提示
A
B
Side View
側視圖
1
Front Suspension 前擺臂懸吊組
STEP6
〈Front Bumper〉
〈前防撞板〉
Front Suspension 前擺臂懸吊組
STEP6
〈For Left〉
〈左側組件〉
3x12 mm
BT Machine Screw
半圓頭內六角螺絲
4
4
10x15x4 mm
Ball Bearing
軸承
1
6mm(L)
Ball Stud
球頭座
2
2
Caster Block Bushing
C型輪座
3
2
4
1
3
3
1
Marked "L"
標示 "L"
Marked "R"
標示 "R"
A B
A B
A
A
Toe Adjustment
前束角調整
For Ready Set Steering Linkage
For Optional Turnbuckle Linkage
8
1
1
4
3x5 mm
F/H Philip Machine Screw
平頭十字螺絲
Apply grease
使用潤滑油膏(黃油)
In the chassis set,
these dog bones have
been assembled in
one-piece unit.
原廠組配已完成
適用原廠固定式轉向拉桿
適用改裝可調式轉向拉桿
