Thunderobot ST PLUS - Interface; Communication; Card Reader; Environmental Spec

22 ST PLUS ENGLISH
ENGLISH ST PLUS 22
Interface
One USB 2.0 Port
One USB 3.0 (USB 3.1 Gen 1) Type A Port
One USB 3.0 (USB 3.1 Gen 1) Type A Port and one
USB 3.0 (USB 3.1 Gen 1) Type C Port
Or
(Factory Option) One USB 3.1 Gen 2 Type A Port
and one USB 3.1 Gen 2 Type C Port
One HDMI-Out Port
Two Mini DisplayPorts 1.2 One Headphone-Out
Jack One Microphone-In Jack One RJ-45 LAN
Jack
One DC-in Jack
M.2 Slots
Models A & B:
Slot 1 for WLAN and Bluetooth Combo
Module
Slot 2 for SATA/PCIe Gen3 x4 SSD (Factory
Option) Slot 3 for 3G/4G Module
Model C:
Slot 1 for WLAN and Bluetooth Combo Module
Slot 2 for SATA/PCIe Gen3 x4 SSD
Communication
Built-In 10/100/1000Mb Base-TX Ethernet LAN
1.0M HD PC Camera Module
Or
(Factory Option) 2.0M FHD PC Camera Module
(Factory Option - Models A & B Only) 3G or 4G
M.2 Module
WLAN/ Bluetooth M.2 Modules:
(Factory Option) Intel® Wireless-AC 8265
Wireless LAN (802.11ac) + Bluetooth 4.1
(Factory Option) Intel® Wireless-AC 3168
Wireless LAN (802.11ac) + Bluetooth 4.0
Card Reader
Embedded Multi-In-1 Card Reader MMC
(MultiMedia Card) / RS MMC
SD (Secure Digital) / Mini SD / SDHC/ SDXC
Environmental Spec
Temperature
Operating: 5°C - 35°C Non-Operating: -20°C -
60°C
Relative Humidity Operating: 20% - 80% Non-
Operating: 10% - 90%
Power
Full Range AC/DC Adapter
AC Input: 100 - 240V, 50 - 60Hz DC Output:
19.5V, 6.15A (120W)
(Factory Option) Removable 6 Cell Smart
Lithium-Ion Battery Pack, 62WH
(Factory Option) Removable 6 Cell Smart
Lithium-Ion Battery Pack, 47WH
Dimensions & Weight
Models A & B:
378mm (w) * 267mm (d) * 26.9mm (h) 2.5kg
(Barebone with 47WH Battery)
Model C:
418.5mm (w) * 288.7mm (d) * 27.4mm (h) 3.1kg
(Barebone with 47WH Battery)
