9 ST PLUS ENGLISH

ENGLISH ST PLUS 9

System Map: Front View with LCD

Panel Open (Model B)

Figure 3

Front View with LCD Panel Open (Model B)

1. PC Camera

2. *PC Camera LED

*When the PC camera is in use,

the LED will be illuminated.

3. Built-In Array Microphone

4. LCD

5. Power Button

6. Keyboard

7. Touchpad & Buttons

System Map: Front View with LCD

Panel Open (Model C)

Figure 4

Front View with LCD Panel Open (Model A)

1. PC Camera

2. *PC Camera LED

*When the PC camera is in use,

the LED will be illuminated.

3. Built-In Array Microphone

4. LCD

5. Power Button

6. Keyboard

7. Touchpad & Buttons

8. Fingerprint Reader

(Optional)

Wireless Device Operation Aboard

Aircraft

The use of any portable electronic transmission devi-

ces aboard aircraft is usually prohibited.

Make sure the WLAN, Bluetooth & 3G/4G module(s) are

OFF if you are using the computer aboard aircraft by pu-

tting the system in to Airplane Mode.

Note that the Touchpad and Buttons valid

operational area is that indicated within the red

dotted lines.
