ThyssenKrupp Access Citia - Table of Contents

2
xxIM0805-470251
This stair lift Installation and Service Manual has been written
to provide clear and precise instructions for proper installation
procedures of both the Citia A/C and Aveya A/C stair lifts.
Please refer to the Owner's Manual for warranty information and
operating instructions. The Owner's Manual must be given to
the owner of the lift before it is put into service.
Any alterations to the equipment without written authorization
by ThyssenKrupp Access may void the warranty.
If you have questions concerning the installation or service
of the Citia A/C or the Aveya A/C please contact the Service
Department:
ThyssenKrupp Access
4001 East 138th Street
Grandview, MO 64030
800-409-3349
Table of Contents
I. PRELIMINARY CHECKS .......................................................3
A. Installation site requirements ...............................................................3
B. Tools required ......................................................................................3
C. Shipment ..............................................................................................3
II. TYPICAL COMPONENTS ........................................................4
III. INSTALLATION PROCEDURES ............................................4
A. Determine where the track will be installed .........................................4
B. Measure for the track ...........................................................................4
C. Cut the track to length ..........................................................................7
D. Install mounting hardware ...................................................................7
E. Install splice bars ................................................................................7
F. Time the gear rack ...............................................................................8
G. Install lower end cap ............................................................................9
H. Mount the track to the staircase ...........................................................9
I. Install the chassis assembly into the track .........................................10
J. Ground the Power Cable ...................................................................12
K. Install the Top End Cap ......................................................................12
L. Install the Junction Box ......................................................................13
M. Adjust the tracking rollers ..................................................................14
N. Test run the chassis ...........................................................................14
O. Level the seat hub .............................................................................15
P. Install the seat ....................................................................................15
Q. Adjust seat height if desired ...............................................................16
R. Remote control label ..........................................................................16
S. Charging the orientation of the pendant holster .................................16
T. Velcro Pendant Control ......................................................................16
IV. COMPLETION PROCEDURES ............................................17
A. Completion Checklist .........................................................................17
B. Before Leaving the Jobsite ................................................................17
V. E.T.L. REQUIREMENTS ........................................................18
VI. SERVICE INFORMATION....................................................18
A. Generalspecications .......................................................................18
B. Standard equipment ..........................................................................18
C. Control Board Operation Notes .........................................................19
D. Control Board Diagnostics .................................................................19
E. Up/Down Logic ..................................................................................19
F. Whattodoiftheliftisstuckonanallimitswitch ............................19
G. Troubleshooting Flowchart if lift won’t run..........................................20
Important! It is imperative that this manual be read and understood prior to
attempting installation of the stair lift. Also, please observe all cautions and
warnings in this manual, as well as labels on the equipment.
