ThyssenKrupp Access Citia - INSTALL CHASSIS ASSEMBLY INTO TRACK

10
I. INSTALL THE CHASSIS ASSEMBLY INTO
THE TRACK
 NOTE: If you will need to change remote frequencies on
the call/send remote controls do this PRIOR to mounting
the chassis on the track. With the chassis close to the
wall,itmaybecomedifculttoremovetheshroudand
access the control board. Refer to Step C of the Service
Information for instructions on changing the frequency
of the remote control.
 Measureforthelenghtoftheexchain.Theexchain
should be the same length as your track. If it is too long,
snap the chain at the correct link and discard the excess
plastic links.
 Move the chassis to the top landing. Do not pick up
by the plastic shroud. Remove the front seat mounting
cover. You must remove the screws from the back
side of the cover rst.
From the factory the A/C unit will be Right Handed. To
change the handed-ness of the unit remove the cover
from the footrest/seatpost area.
It should look like this:
There will be two harnesses, one marked RH (right
hand) and one marked LH (left hand). Plug in the har-
ness that corresponds with the handed-ness of the
unit.
Right
Hand
Harness
Left Hand
Harness
