MEASURES, LOGIC STATES AND COUNTERS
46
NA011 - Manual - 05 - 2022
5 MEASURES, LOGIC STATES AND COUNTERS 5 MEASURES, LOGIC STATES AND COUNTERS
Measures
RMS value of fundamental component for phase currents (I
L1
, I
L2
, I
L3
)
RMS value of fundamental component for measured residual current (I
E
)
Circuit breaker
The CB and 79 states are provided
Position Open - Closed - Unknown
Binary inputs
The input states are provided
IN1 input ON/OFF
IN2 input ON/OFF
IN3 input ON/OFF
Counters
For every protective element and control function several counters are available; the partial coun-
ters can be cleared by the user.
Every partial counter is reset to zero when ten thousand count is passed.
All partial counters can be cleared by means a single command; for this purpose the Reset coun-
ters command must be issued available inside the Reset menu.
Counter ST I> (start I> element)
Counter ST I>> (start I>> element)
Counter ST I>>> (start I>>> element)
Counter ST IE> (start IE> element)
Counter ST IE>> (start IE>> element)
Counter TR I> (trip I> element)
Counter TR I>> (trip I>> element)
Counter TR I>>> (trip I>>> element)
Counter TR IE> (trip IE> element)
Counter TR IE>> (trip IE>> element)
Counter TR EXT (Remote trip)
Counter 79 RR (Rapid reclosures)
Counter 79 SR (Slow reclosures)
Counter 79 DR (Delayed reclosures)
Counter 79 FR P (Failed reclosures from 50/51 trip)
Counter 79 FR E (Failed reclosures from 50N/51N trip)
Counter 79 FR X (Failed reclosures from external trigger)
Fault recording - SFR
Recording
[1]
is triggered by:
Relay activation (OFF-ON)
External trigger (binary input) programmed as Fault trigger
Element start or trip
Twenty faults are recorded into a circular FIFO (First In, First Out) buffer.
[2]
Following information are stored in every record:
Read \ Faults \ Info menu
Faults stored
[3]
Last fault
Read \ Faults \ Fault menu
Fault number (F-Number)
Fault Cause (F-Cause)
Fault Phases (F-Phases)
Phase currents (F-IL1, F-IL2, F-IL3)
Residual current I
Er
F-IE)
Date and time (F-Year)
Date and time (F-Year)
Date and time (F-Month)
...
Date and time (F-Millisecond)
The fault log may be erased by means of the command available inside the Read \ Faults \ Reset
menu.
Event recording - Events
Recording is triggered by:
Power up and/or Power down.
Element start or trip.
Binary input switch (OFF-ON or ON-OFF).
Setting modify.
Note 1 Data concerning the twenty events are stored into non volatile memory; they are held in spite of power down
Note 2 Fault 0 is the newest event, while the Fault 19 is the oldest event
Note 3 Counter is updated at any new record; it may be cleared by means ThyVisor
