SETTING AND COMMISSIONING
63
NA011 - Manual - 05 - 2022
7.3 MENU TREE
Description Parameter Unit Setting range
Read
Info
Code NA011-CB0-d
Serial
Firmware release 0 ... 0 step = 0
Nominal freq. Hz 0 ... 0 step = 0
Clock
Year 2000 ... 2099 step = 1
Month 1 ... 12 step = 1
Day 1 ... 31 step = 1
Hour h 0 ... 23 step = 1
Minute m 0 ... 59 step = 1
Second s 0 ... 59 step = 1
Measures
IL1 A/In 0 ... 0 step = 0
IL2 A/In 0 ... 0 step = 0
IL3 A/In 0 ... 0 step = 0
IE A/IEn 0 ... 0 step = 0
Inp value 1 ... 99 step = 1
100 ... 5000 step = 5
Inp unit A
IEnp value 1 ... 99 step = 1
100 ... 5000 step = 5
IEnp unit A
Reading Relative | Direct
Protections trip
Protections trip Trip I> | Trip I>> | Trip I>>> | Trip IE> | Trip IE>> |
Trip EXT
AutoReclose - 79
79 ActiveMode OFF | ON
79 Run OFF | ON
79 CycleState Reset | Disabled | Blocked | Off | Rapid | Slow |
Delayed | Discrimination | Neutralization | Fail
79 Residual-time s 0 ... 0 step = 0
79 LastEvent None | Disable | Block | Enable | Start | Manual
close | Rapid | Slow | Delayed | Rapid OK | Slow
OK | Delayed OK | Interrupted | Fail phase | Fail
earth | Fail ext
Circuit breaker
Position Unknown | Open | Closed | Alarm
Digital inputs
IN1 input OFF | ON
IN2 input OFF | ON
IN3 input OFF | ON
