SETTING AND COMMISSIONING
64
NA011 - Manual - 05 - 2022
Counters
Counter ST I> 0 ... 10000 step = 1
Counter ST I>> 0 ... 10000 step = 1
Counter ST I>>> 0 ... 10000 step = 1
Counter ST IE> 0 ... 10000 step = 1
Counter ST IE>> 0 ... 10000 step = 1
Counter TR I> 0 ... 10000 step = 1
Counter TR I>> 0 ... 10000 step = 1
Counter TR I>>> 0 ... 10000 step = 1
Counter TR IE> 0 ... 10000 step = 1
Counter TR IE>> 0 ... 10000 step = 1
Counter TR EXT 0 ... 10000 step = 1
Counter 79 RR 0 ... 10000 step = 1
Counter 79 SR 0 ... 10000 step = 1
Counter 79 DR 0 ... 10000 step = 1
Counter 79 FR P 0 ... 10000 step = 1
Counter 79 FR E 0 ... 10000 step = 1
Counter 79 FR X 0 ... 10000 step = 1
Self-test
Self-test None | Minor | Major | Fatal
Self-test cause Stack overflow | reserved | Eeprom overflow |
Eeprom CAL fail | Eeprom PAR fail | Eeprom REE
fail | reserved | reserved | Breaker Failure
Self-test latch Stack overflow | reserved | Eeprom overflow |
Eeprom CAL fail | Eeprom PAR fail | Eeprom REE
fail | reserved | reserved | Breaker Failure
Faults
Info
Faults stored 0 ... 20 step = 1
Last fault 0 ... 20 step = 1
Fault
F - Number 0 ... 20 step = 1
F - Cause None | Start I> | Start I>> | Start I>>> | Start IE> |
Start IE>> | Trip I> | Trip I>> | Trip I>>> | Trip IE> |
Trip IE>> | Trip EXT
F - Phases IL1 | IL2 | IL3
F - IL1 In 0 ... 0 step = 0
F - IL2 In 0 ... 0 step = 0
F - IL3 In 0 ... 0 step = 0
F - IE IEn 0 ... 0 step = 0
F - Year 2000 ... 2099 step = 1
F - Month 1 ... 12 step = 1
F - Day 1 ... 31 step = 1
F - Hour h 0 ... 23 step = 1
F - Minute m 0 ... 59 step = 1
F - Second s 0 ... 59 step = 1
