SETTING AND COMMISSIONING
65
NA011 - Manual - 05 - 2022
F - Millisecond ms 0 ... 999 step = 1
Reset
Events
Info
Events stored 0 ... 50 step = 1
Last event 0 ... 50 step = 1
Event
E - Number 0 ... 50 step = 1
E - Cause None | Overflow | Power down | Power up | Start
I> | Start I>> | Start I>>> | Start IE> | Start IE>> |
Trip I> | Trip I>> | Trip I>>> | Trip IE> | Trip IE>> |
Trip EXT | BF ON | BF OFF | IN1 ON | IN1 OFF | IN2
ON | IN2 OFF | IN3 ON | IN3 OFF | ALARM CB ON
| ALARM CB OFF | CB open MMI | CB close MMI |
CB open MBUS | CB close MBUS | CB open P103 |
CB close P103 | 79 disabled | 79 blocked | 79 ena-
bled | 79 manual close | 79 start | 79 rapid close |
79 slow close | 79 delayed close | 79 interrupted
| 79 fail phase | 79 fail earth | 79 fail external | 79
rapid ok | 79 slow ok | 79 delayed ok
E - Year 2000 ... 2099 step = 1
E - Month 1 ... 12 step = 1
E - Day 1 ... 31 step = 1
E - Hour h 0 ... 23 step = 1
E - Minute m 0 ... 59 step = 1
E - Second s 0 ... 59 step = 1
E - Millisecond ms 0 ... 999 step = 1
Reset
Set
Base
Inp value 1 ... 99 step = 1
100 ... 5000 step = 5
Inp unit A
IEnp value 1 ... 99 step = 1
100 ... 5000 step = 5
IEnp unit A
Reading Relative | Direct
Digital inputs
IN1 select None | 52b | Trip EXT
IN2 select None | 52a | Trip EXT | CB Open
IN3 select None | 79 Enable | 79 Remote | Trip EXT | CB Close
Relays
K1 Self Test | Start I> | Start I>> | Start I>>> | Start IE>
| Start IE>> | Trip I> | Trip I>> | Trip I>>> | Trip IE> |
Trip IE>> | Trip EXT | Breaker Failure | 79 Close | 79
Run | 79 Fail | CB Close | CB Open | Self Test CB
K1 logic De-energized | Energized
K1 mode No-latched | Latched
K1 tTR ms 10 ... 500 step = 10
