SETTING AND COMMISSIONING
66
NA011 - Manual - 05 - 2022
K2 Self Test | Start I> | Start I>> | Start I>>> | Start IE>
| Start IE>> | Trip I> | Trip I>> | Trip I>>> | Trip IE> |
Trip IE>> | Trip EXT | Breaker Failure | 79 Close | 79
Run | 79 Fail | CB Close | CB Open | Self Test CB
K2 logic De-energized | Energized
K2 mode No-latched | Latched
K2 tTR ms 10 ... 500 step = 10
K3 Self Test | Start I> | Start I>> | Start I>>> | Start IE>
| Start IE>> | Trip I> | Trip I>> | Trip I>>> | Trip IE> |
Trip IE>> | Trip EXT | Breaker Failure | 79 Close | 79
Run | 79 Fail | CB Close | CB Open | Self Test CB
K3 logic De-energized | Energized
K3 mode No-latched | Latched
K3 tTR ms 10 ... 500 step = 10
K4 Self Test | Start I> | Start I>> | Start I>>> | Start IE>
| Start IE>> | Trip I> | Trip I>> | Trip I>>> | Trip IE> |
Trip IE>> | Trip EXT | Breaker Failure | 79 Close | 79
Run | 79 Fail | CB Close | CB Open | Self Test CB
K4 logic De-energized | Energized
K4 mode No-latched | Latched
K4 tTR ms 10 ... 500 step = 10
AutoReclose - 79
79 Enable OFF | ON
79 Mode Rapid | Rapid+Slow
79 N.DAR 0 ... 5 step = 1
79 trdt s 0.1 ... 19.9 step = 0.1
20 ... 60 step = 1
79 tsdt s 1 ... 200 step = 1
79 td s 0 ... 10 step = 1
79 tr s 1 ... 200 step = 1
79 MC-td-EN OFF | ON
79 MO-RES OFF | ON
79 Trigger Trip I> | Trip I>> | Trip I>>> | Trip IE> | Trip IE>> |
Trip REMOTE
50/51
I> Element
I> Setpoint
I>Curve DEFINITE | IEC/BS A | IEC/BS B | IEC/BS C | ANSI/
IEEE MI | ANSI/IEEE VI | ANSI/IEEE EI | I2T
ICLP> Off | On-Blocking | On-Changing
tCLP> s 0.00 ... 9.99 step = 0.01
10.0 ... 100.0 step = 0.1
t>RES ms 0 ... 1000 step = 10
I> Definite
I>def In 0.100 ... 0.999 step = 0.001
1.00 ... 9.99 step = 0.01
10.0 ... 20.0 step = 0.1
ICLP>def In 0.100 ... 0.999 step = 0.001
1.00 ... 9.99 step = 0.01
10.0 ... 20.0 step = 0.1
t>def s 0.03 ... 10.00 step = 0.01
