SETTING AND COMMISSIONING
67
NA011 - Manual - 05 - 2022
I> Inverse
I>inv In 0.100 ... 0.999 step = 0.001
1.00 ... 2.50 step = 0.01
ICLP>inv In 0.100 ... 0.999 step = 0.001
1.00 ... 10.00 step = 0.01
t>inv s 0.02 ... 9.99 step = 0.01
10.0 ... 60.0 step = 0.1
I>> Element
I>> Setpoint
ICLP>> Off | On-Blocking | On-Changing
tCLP>> s 0.00 ... 9.99 step = 0.01
10.0 ... 100.0 step = 0.1
t>>RES ms 0 ... 1000 step = 10
I>> Definite
I>>def In 0.100 ... 0.999 step = 0.001
1.00 ... 9.99 step = 0.01
10.0 ... 20.0 step = 0.1
ICLP>>def In 0.100 ... 0.999 step = 0.001
1.00 ... 9.99 step = 0.01
10.0 ... 20.0 step = 0.1
t>>def s 0.03 ... 10.00 step = 0.01
I>>> Element
I>>> Setpoint
ICLP>>> Off | On-Blocking | On-Changing
tCLP>>> s 0.00 ... 9.99 step = 0.01
10.0 ... 100.0 step = 0.1
t>>>RES ms 0 ... 1000 step = 10
I>>> Definite
I>>>def In 0.100 ... 0.999 step = 0.001
1.00 ... 9.99 step = 0.01
10.0 ... 20.0 step = 0.1
ICLP>>>def In 0.100 ... 0.999 step = 0.001
1.00 ... 9.99 step = 0.01
10.0 ... 20.0 step = 0.1
t>>>def s 0.03 ... 10.00 step = 0.01
50N/51N
IE> Element
IE> Setpoint
IE>Curve DEFINITE | IEC/BS A | IEC/BS B | IEC/BS C | ANSI/
IEEE MI | ANSI/IEEE VI | ANSI/IEEE EI | I2T
IECLP> Off | On-Blocking | On-Changing
tECLP> s 0.00 ... 9.99 step = 0.01
10.0 ... 100.0 step = 0.1
tE>RES ms 0 ... 1000 step = 10
IE> Definite
IE>def IEn 0.005 ... 0.999 step = 0.001
1.00 ... 5.00 step = 0.01
IECLP>def IEn 0.005 ... 0.999 step = 0.001
1.00 ... 5.00 step = 0.01
tE>def s 0.03 ... 10.00 step = 0.01
IE> Inverse
IE>inv In 0.005 ... 0.999 step = 0.001
1.00 ... 2.00 step = 0.01
