TECHNICAL DATA
13
NA016 - Manual - 05 - 2022
3.2 INPUT CIRCUITS
Auxiliary power supply
U
aux
Voltage
Nominal value (range)
[1]
24...230 V~/-
Operative range 19...265 V~/19...300 V-
Inrush current (max)
• 24 V- 3 A, 1 ms
• 48 V- 5 A, 1 ms
• 110 V- 10 A, 1 ms
• 230 V~ 40 A, 1 ms
Frequency (for alternate voltage supply) 45...66 Hz
Max distortion factor ( for alternating voltage supply) 15%
Max alternating component (for dc voltage supply):
• Full wave rectified sine wave 100 %
• Sine wave 80 %
Power consumption:
• Maximum (energized relays, three LEDs, backlight ON) 4.5 W (U
AUX
= 24 V-)
• Maximum (energized relays, three LEDs, backlight ON) 9 VA (U
AUX
= 230 V~)
Phase current input circuits
Standard CTs:
Connections M4 terminals
Relay nominal phase current I
n
1 A or 5 A selectable by DIP-switch
Permanent overload 25 A
Thermal overload (1 s) 500 A
Dynamic overload (half cycle) 1250 A
Rated consumption (for any phase) ≤ 0.002 VA with I
n
=1 A
≤ 0.04 VA with I
n
=5 A
LPCT - Low Power Current Transformers:
Connections RJ45 plug
Relay nominal phase current I
n
100 A
Extended primary current 50 A...1250 A selectable by DIP-switch
Max primary current 12.5 kA
Nominal secondary voltage (with I
np
= 100 A) 22.5 mV
Residual current input circuit
Relay nominal residual current I
En
1 A or 5 A selectable by DIP-switch
Permanent overload 25 A
Thermal overload (1 s) 500 A
Dynamic overload (half cycle) 1250 A
Rated consumption ≤ 0.006 VA with I
En
=1 A
≤ 0.12 VA with I
En
=5 A
Binary input circuits
Quantity 2
Type optocoupler
Operative range 24...265 V~/-
Min activation voltage U
DIGmin
18 V
Max consumption, energized 3 mA
3.3 OUTPUT CIRCUITS
Output relays
Quantity 4
Type of contacts changeover (SPDT, type C)
Nominal current 8 A
Nominal voltage/max switching voltage 250 V~/400 V~
Breaking capacity:
• Direct current (L/R = 40 ms) 50 W (K1, K2, K4 trip)
• Direct current (L/R = 40 ms) 30 W (K3 signalling)
• Alternating current (l = 0,4) 1250 VA
Make 1000 W/VA
Short duration current (0,5 s) 30 A
Minimum switching load 300 mW (5 V/ 5 mA)
Life:
• Mechanical 10
6
operations
Electrical 10
5
operations
Minimum pulse width (K1t
TR
...K4t
TR
) 0.01...0.50 s (step 0.01 s)
Note 1 The different versions must be select on order
