SETTING AND COMMISSIONING
54
NA016 - Manual - 05 - 2022
Store command, located in the “Set” menu has been used; in this regard, once the “Store” mes-
sage is displayed, it is necessary to use the Enter button; this results in the “execute” message
with the symbol “C” flashing.
• Browse the menu by means of the Left and Up or Down keys to go in the Store menu.
• Press the Enter button; once more concludes the save procedure with the temporary appearance
of the message “ok!”.
After one or more modifications, the status of having data that has still not been permanently saved
is indicated by the “!” symbol in the top right and the display message “WARNING set Clear..
Store” which appears while browsing through the main menu with the use of the Up or Down keys.
• The Clear command may be used to abandon unsaved changes (prior to use of the Store com-
mand); the same effect is achieved by switching the key to the OFF position or removing the auxil-
iary power supply to the relay.
Example
To set the K1 relay with Energized mode and latched mode (Energized, Latched) the following
sequence must be operated:
• Select the Set menu “Set >”by means of the Down key.
• Press the Right key; the message “Base >” is displayed.
• Browse the menus with Down
“Relays >”
“50/51 >”
“50N/51N >”
“Circuit breaker >”
“Clear >”
“Store >”
• Select the “Relays >”, menu; the message “K1 None >” is displayed.
• Press the Down key; the message “K1 Logic De-energized” is displayed.
• Press the Enter key; the he modification in progress status is highlighted by the symbol “E” flashing
in the upper right area of the display.
• Change the parameter by means the Up or Down keys; the message “K1 Logic Energized” is
displayed.
• Press the Enter key; acceptance of the change is indicated by the disappearance of the flashing
“E” to be replaced by the symbol “!”.
• Press the Down key; the message “K1 mode No-latched” is displayed.
• Press the Enter key; acceptance of the change is indicated by the disappearance of the flashing
“E” to be replaced by the symbol “!”.
• Change the parameter by means the Up (increment) or Down (decrement) buttons; the message “K1
mode Latched” is displayed.
• Press the Enter button; acceptance of the change is indicated by the disappearance of the flashing
“E” to be replaced by the symbol “!”
• Press the Left key and Up or Down to go inside the Store menu.
• Press the Enter key; this results in the “execute ?” message with the symbol “C” flashing.
• Answer with Enter key to confirm setting.
The end of the setting sequence is signalled by the “ok!” message.
The Reset key may be used to abort unsaved changes (prior to use of the Store command); the same
effect is achieved by switching the key to the OFF position or removing the auxiliary power supply to
the NA011 relay.
Test
The operational tests with or without command of the associated output relays may be performed.
Browse the main menu by means the Up or Down keys until the “Test” message is displayed; press
the Enter key to enter and subsequently select the test by means of the Up or Down keys.
• Test I> led
• Test I>> led
• Test I>>> led
• Test IE> led
• Test IE>> led
• Test I> full
• Test I>> full
• Test I>>> full
• Test IE> full
• Test IE>> full
