INTRODUCTION
11
Symbols.ai
Symbols
I>> Start
I>> BF_OUT
IPh Block2
Logic internal signal (output); may be a logical state
(e.g.I>> Start
) or a numerical value
It is available for reading (ThyVisor + communication interface)
Logic external signal (intput); may be a command coming from a binary input or a sw command
It is available for reading (ThyVisor + communication interface)
Internal signal (e.g. Breaker Failure output state concerning to the 2nd threshold of the 50 element)
It is not available for reading (missing arrow)
AND and NAND logic gates
OR and NOR logic gates
Limit block (I>> threshold).
Computation block (Max phase current)
Threshold setting (e.g. pickup
I>>)
.
The value is available for reading and is adjustable by means ThyVisor + MMI.
Switch
ON delay timer with reset (
t
ON
delay)
ON delay timer without reset (
t
ON
delay)
Curve type (definite/inverse time)
0T
I
L3
Max[I
L1
,I
L2
,I
L3
]
I
L2
I
L1
t
ON
t
ON
t
ON
t
ON
t
RESET
INPUT
OUTPUT
t
ON
t
ON
t
ON
t
INPUT
OUTPUT
0T
t
ON
& &
1 1
EXOR logic gate
=1
I>>
I
I ≥
I>>
t
ON
RESET
0T
SR
S1
R
Q1
Flip Flop set-dominant
MMI (Man Machine Interface) Operator front panel
ThyVisor Setting and monitoring software
Subnet Mask (Ethernet nomenclature)
Sw Software
Fw Firmware
Upgrade Firmware upgrade
XML eXtensible Markup LanguageXML
Upgrade Firmware upgrade
