16
Reminding: the initial temperature setting range is 35.0°C ~100.0°C.
Reminding: the target temperature setting range is 35.0°C ~100.0°C.
Reminding: the delta temperature setting range is 0.1°C ~5.0°C.
Reminding: the star cycle range is 1~ max cycle number of the current stage.
Figure 3-3-6 Step Edit Window - Touchdown Step Mode Parameters Setting
3) If the selected option is Long step mode, the step edit window will be shown as figure
3-3-7.
