6. Now go to the wireless broadcast Transmitter. Find the
transmitters mains/ transformer power supply and plug in. Attach
the other end to the transmitter and you should see a Green LED
light showing the unit is powered and ready to transmit.
7. There are two music source cables supplied with your TIC
wireless speaker(s). Note: the transmitter only takes a 3.5mm
jack input. (1) This cable supplied is a 3.5mm jack to 3.5mm jack
that is useful for connecting your wireless speaker(s) transmitter
to CD, MP3, IPods, computers, headphones and other modern
devices which have a 3.5mm jack output connection. (2) This
connection cable supplied has a 3.5mm jack at one end for the
transmitter connection and a “Y” type, 2x RCA plugs at the other.
This cable is useful for connecting your transmitter to RCA type
plug outputs like those found on TV’s, audio amplifiers, AV
receivers and devices which only have RCA plug type audio
outputs. Note: such audio outputs usually follow the standard
audio output color code of Red & White.
8. It is important you ensure your choice of music source or connection method is
operating and producing a signal the transmitter can broadcast to the speaker(s). A
quick check method is prior to plugging in the transmitter make sure the chosen
music source is producing sound normally. An earphone connection is the easiest
way as the music will stop when connected in this fashion and you can ensure the
signal passes to the transmitter. Please ensure sufficient Volume is being
produced, the right “mode” if any, is chosen and that the “mute” switch is not on.
