22
www.timberk.com Storage water heater
N
L
Fig.19
1
2
3
Heating
element 1
Heating
element 2
t° sensor
Actuating unit
Control unit
(programmer, control t°, etc)
Thermal switch
11. DISPOSAL
The water heater should be disposed upon the end of life. You can
obtain detailed information on water heater disposal from a
representative of local authorities.
Device service life is 10 years.
NOTE:
Technical and any other characteristics of the appliance can be revised.
Such changes may be introduced without warning and prior notice to
the consumers.
The manufacturer shall not be liable for changes in the appliance's
wiring diagram that may be implemented without notice to the
consumers.
10. WIRING DIAGRAM
Fig.18
Plug
Thermostat
Switcher of power
modes
Brown
Blue
Yellow-green
Temperature
limiter
Heating indicator
light
Heater 1
Heater 2
For models FS1/FS2
For models FS5/FS6/FE1/FE2
