9
5. DELIVERY SET
1. Water heater 1 pc.
2. Remote control 1 pc.*
3. Anchor bolt 2 pcs.
4. Pressure safety valve 1 pc.
5. Discharge pipe 1 pc.
6. Operation manual 1 pc.
7. Guarantee card 1 pc.
8. Packing 1 pc.
* only for FS5/FS6 series
6. WATER HEATER INSTALLATION
Location
1. Electric water heater should be mounted on a firm wall. If the wall is not
robust enough to hold the weight equal to the doubled weight of the total
water heater weight, fully filled with water, then it should be mounted on a
special support.
2. The wall, where the electric water heater is to be mounted, must
withstand at least the double weight of the water heater, fully filled with
water; there must be no cracks and other damages on the wall. Otherwise
it is necessary to take measures to strengthen the mounting or mount the
water heater on a special support.
3. If a bathroom is too small, the water heater can be installed elsewhere,
unexposed to direct sunlight and unavailable for moisture. However, to
reduce heat losses in pipelines, the location, where a water heater is to be
installed, must be as close to the place, where hot water is used, as possible.
IMPORTANT!
The water heater must be mounted on a vertical wall only the
position, specified in Fig.3-4 (FS1/FS5/FE1 line vertically,
FS2/FS6/FE2 horizontally). Mounting of the appliance in any
other position or vertical or horizontal tilting will inevitably result
in failure of the water heater, emergency situation and is
considered a non-guarantee case by the manufacturer.
www.timberk.com Storage water heater
ENGLISH
