48
Item Part No Part Name Q’ty
1 0360 M10/25 Bolt 1
2 0839 M10 C Washer 1
3 17350M Rotor Shaft 1
4 1527 M8/25 Caphead 8
5 1937M Bearing Cap 1
6 2943 Oil Seal 1
7 1939 Bearing 6309 1
8 18712M Blade Bolt 2
9 18513M Rotor Disc 1
10 18692MH 5” Blade 2
Item Part No Part Name Q’ty
11 0355 M8/16 CSK Bolt 4
12 2902MS Bolt Plate 2
13 1940MS Bearing Spacer 1
14 1218 M16 Hardened Washer 4
15 1284 M16 T Nyloc Nut 4
16 1862 Bearing 6308 1
17 1893 Nut M39/4 1
18 2983MS Drive Adapter 1
19 0701 M10 A Washer 6
20 4054 M10/35 Finethread Capheads 6
8
12
17
16
10
13
Date Last Modified: 13th Feb 09
9
11
4
5
7
x8
18
20
x6
6
1
2
3
14
19
15
TIMBERWOLF
TW 190TDHB
ROTOR
