TIMBERWOLF
TW 230DHB
39
ELECTRICAL LAYOUT
ITEM PART NO DESCRIPTION QTY
1 P*1335 Funnel Loom 1
3 P*1337 Main Engine Loom 1
ITEM PART NO DESCRIPTION QTY
4 1375
+
VEBattery Cable 1
5 1376
-
VEBattery Cable 1
1
2
3
4
3
4
2
