Timeguard TRT036N - TRT036 N Front View and Specifications; Front Panel Overview; Battery Backup and Dimensions

2
• Battery Backup: 7 day, factory fitted rechargeable
(non-replaceable)
• Illumination: Blue LED illuminated on setting
for button surrounds and display
• CE Compliant
• Dimensions (H x W x D): 90 x 135 x 30mm
TRT036N Front View
12hr am/pm or 24hr clock timer
display (illuminated on setting)
The heating
symbol will
show when
heat is
demanded for
both channels
Flip down
cover conceals
setting buttons
Advance to next Programme,
ON/OFF override and copy function
Up down selection
buttons
1, 2 and 3 hour
heating boost function
(illuminates on setting)
Display light/Holiday
mode setting button
1, 2 and 3 hour
hot water boost
function (illuminates
on setting)
