Detailed solution of parameters:
P-01, gate lift speed
All where the speed is involved, the percentage of the maximum speed of the motor
is taken. If the maximum speed of the motor is 1800rpm and the set value is 80,
the maximum speed runs at 1440rpm.
P-02, Strip speed
The same lifting speed.
P-03
For setting the motor deceleration during gate lift.In angle, 0 degrees for
horizontal position and 90 degrees in vertical position.This parameter indicates
the start of slow down when the lever is opened at this angle from the vertical
position.
P-04
For setting the motor deceleration stroke during the drop trip.In angle, 0 degrees
for horizontal position and 90 degrees in vertical position.This parameter
indicates the initial deceleration when the gate lever falls to this angle from
the horizontal position.
P-05 gate lift and acceleration time
Unit: 0.01 seconds, acceleration to lift speed.This parameter determines the
acceleration of the gate lift.
P-06 shutdown acceleration time
Unit: 0.01 seconds, time to trip speed.This parameter determines the acceleration
of the shutdown gate.
P-07 lift end speed
At this speed to lift the gate, too small will lead to open not in place, too large
will lead to shaking.If the P-11 command has set a low lift angle and is in the
effective range, run at that speed in the low speed uniform zone.
P-08 shutdown end speed
At this speed to close the gate, too small will lead to close not in place, too
big will lead to shaking.If the P-12 command is set at the drop gate low speed
angle and is in the effective range, run at that speed in the low speed uniform
zone.
P-09 horizontal position regulation
If the gate lever is uneven horizontally, it can be fine-tuned by this
parameter.For gates with rubber ring as a buffer, this value needs to be increased
to avoid squeezing the rubber ring at each closing.
The P-10 vertical position adjustment
If the gate bar is not positioned vertically, it can be fine-tuned by this
