Titan Controls 8 Light Controller User Manual

4
Troubleshooting Tips
If the 8 Light Controller is not performing as expected, try the following:
a. Contact a certied Electrician to service your 8 Light Controller.
b. Conrm that your power input is active from your power panel and providing
240 volts/60Hz/50 Amps Input to the controller.
c. Check the voltage input using a voltage test meter to verify power is owing to
the controller.
d. Make sure all of your connections are tight. Loose connections can cause “arcing”.
e. After activating relay, conrm that power is active and proper at your 240 Volt outlets.
f. Verify that your power cords and ballasts are functioning properly and that there are
no shorts or arcing occurring.
g. Check ballasts & lights in known 240 volt power source to verify they are working
properly.
h. Still having problems with your 8 Light Controller? Please contact our Technical
Service Representative at (888) 808-4826 to assist you further.
Controller Specifications
• Main Power Voltage = 240 volts
• Wire = Minimum 8 AWG Wire (75° C Cu Wire ONLY)
• Maximum Wattage = 8,000 Watts (1000 Watts per outlet)
• Maximum Input Amperage = 50 Amps
• Maximum Output Amperage = 40 Amps
• Relay Coil Voltage = 120V AC
• Hertz = 60Hz
• Receptacle Type = Universal
• Operating Temperature = 40- 25° F (4.5 -52° C)
• Storage Temperature = 32-135° F (0 - 57° C)
• Size = 14.76” H x 13.47” W x 5.15” D
• Weight = 13.0 lbs
• RoHS compliant = Yes
Notes
