Section 3: Required Build Materials
Spars needed (solid rod if no OD/ID specified):
• (1) 10 OD x 8 ID x 1000mm - front main wing spar
• (1) 8 OD x 6 ID x1000mm - rear main wing spar
• (2) 8 OD x 6 ID x 800mm – inner wing spar
• (2) 4x600mm - flap/aileron hinge
• (2) 4x400mm - wingtip support
Conventional tail:
• (1) 4x500mm - hstab support
• (1) 3x500mm - elevator hinge
• (1) 4x170mm - vstab support
• (1) 3x220mm - rudder hinge
Vtail:
• (2) 4x250mm - ruddervator hinge
• (2) 4x150mm - stab support
Recommended motor & prop:
• 19-25mm mounting pattern
• BrotherHobby 2816 620kV and APC 11x8 CW/CCW props (this is only a suggestion,
there are hundreds of other motor and prop combos that would work)
• 11-14 inch propellers – choose according to your build goals
Recommended electronics:
• ELRS / Dragonlink / TBS Crossfire
• 5.8ghz / 1.2ghz analog or digital. Supports DJI / Walksnail / SIYI as well
• Matek F405-WTE or similar flight controller running Ardupilot (optional)
• Matek M10Q-5883 GPS/Compass or similar (optional)
• (2) 35A BLHeli ESC or 51a Lumenier Blheli32 ESC with telemetry
• (7) Emax ES08MAII servos (6 if using V-Tail)
• Li-Ion Battery: 6S3P 21700 15Ah, 6S4P 21700 20Ah, 6S8P 18650 28Ah
• LiPo Battery: 6S 6Ah, 6S 8Ah, 6S 10Ah, 4S 14Ah (many other options…)
Misc:
• Polymaker Polylite prefoamed LWPLA
• PETG or other high-temp filament for the motor mount
• Medium CA glue
• 220x220x240 minimum size print bed
• Control horns and rods
• M3 threaded inserts (max 6mm height)
• M3 bolts of various sizes (countersunk ones as well)
• 6x3mm magnets
