Section 2: Model Specifications & Performance
2.1: Physical Characteristics
General Stats:
• Wingspan: 2093mm
• Wing area: 4514cm
2
• Maximum take-off Weight: 7kg
• Efficiency: 1.6 Wh/km @ 3.5kg AUW
• Cruise speed: 45-65kph
• Recommended prop diameter: 11-14 inches
Aerodynamic Properties:
• Root airfoil: NACA 4411
• Tip airfoil: NACA 3411
• Stabilizer airfoil (inverted): NACA 2410
• Root chord: 260mm
• Tip chord: 51mm
• Average chord: 176mm
• Root incidence: 4°
• Tip incidence: 0°
• Aspect ratio: 9.71
• Dihedral: 0.5°
• Sweep: 3°
